About
Specs
Overview
| Exterior Dimensions (H x W x D) |
60.5" x 42" x 32" |
|---|---|
| MIN. DOORWAY WIDTH CLEARANCE TO DELIVER SAFE* |
30" |
| Gun Storage | 64 (2 collector racks with 32 guns each) |
PLEASE NOTE: |
|
| Fire Rating | 75 MIN. FIRE RATING |
| Body Steel Thickness | 11 Gauge |
| Weight | 896 lbs. |
| Warranty | Limited Lifetime Transferable |
| Country of Origin | MADE IN THE USA |
| Price Match Guarantee | YES |
We will beat any advertised price on the same product. |
|
Dimensions
| Exterior Dimensions (H x W x D) |
60.5" x 42" x 32" |
|---|---|
| Overall Exterior Depth (with handle installed) |
32" |
| Interior Dimensions (H x W x D) |
56.5" x 38" x 20" |
| Clear Door | |
| FOOTPRINT (W x D) |
42" x 27.5" |
| Exterior Cubic Feet (safe body only) |
40.4 |
| Interior Cubic Feet | 24.8 |
| Door Swing Projection at 90° | N/A |
| Door Swing Projection at 180° | N/A |
Fire Protection
| Fire Rating | 75 MINUTES @ 1200° F |
|---|---|
| Fire Temp | 1200° Fahrenheit with 10 minute ramp up. Interior temperature did not exceed 350° F |
| Fire Insulation Type | 4 in ceiling, door jambs and door, 2 in walls |
| Door Seal | Heat-Activated, Expanding Palusol™ |
| Smoke Seal | Yes |
Security
| Security Rating | U.L. RSC |
|---|---|
| Door Bar / Bolt Sides | 4 Sides, ¼” thick locking bars |
| Bar / Bolt Count | 12 |
| Bar / Bolt Type | 4-Inch Wide by 1/4" Thick Military Style Locking Bars |
| Locking Mechanism Type | Monster Mech DX-90, Over-Center Cam-Drive |
| Door Type | Composite |
| Door Thickness | 4.5" total with 1" composite door front |
| Body Steel Thickness | 11 Gauge |
| Total Body Thickness | 1-3/8" Steel and Fireboard, 2-5/8" in Ceiling |
| Main Lock | Upgraded S&G™ 6730 mechanical lock (with key locking dial) standard with optional upgrade to SecuRam ProLogic electronic lock |
| Secondary Lock | N/A |
| Relocker Type | Fail-Safe™, Punch and Drill |
| Hardplate Lock Protection | Triple RC63 hardplates |
| Anchor Holes | (4) 5/8" Floor |
Style
| Exterior Finish | Powder Coat |
|---|---|
| Fabric Type | Gray Fabric |
| Upholstery | Fully Upholstered |
| Handle Style | 3-Spoke |
| Interior Type | 4-in-1 Flex™ |
| Interior Lighting | Battery operated, dual Brightview wand light kit |
| Power Access Hole | Yes |
| Door Panel | Yes, Deluxe |
