About
The new Amvaultx6 U.L. Listed TL-30×6, six-sided high security composite safes are made in the United States using the latest testing procedures set forth by Underwriters Laboratories. The new revolutionary Amvaultx6 is constructed with a 3” defense barrier of inner and outer steel plates enclosing a unique interlocking heavy duty steel barrier, high strength concrete exceeding 12,000 PSI and a high-density high-strength ceramic matrix. The high density insulating materials incorporated in the door and body also insure two hours of certified fire protection. The superior design and craftsmanship make the new Amvaultx6 impervious to burglary attacks attempted by the most sophisticated equipment utilized today and the vaults contents against intense fires.
Specs
Overview
| Exterior Dimensions (H x W x D) |
31" x 26" x 25.25" |
|---|---|
| MIN. DOORWAY WIDTH CLEARANCE TO DELIVER SAFE* |
28" |
| Gun Storage | 1 Shelf (Tan) |
PLEASE NOTE: |
|
| Fire Rating | 2 Hour Fire Rating |
| Body Steel Thickness | Propreitary, Not Disclosed |
| Weight | 1,433 lbs. |
| Warranty | More Info |
| Country of Origin | MADE IN THE USA |
| Price Match Guarantee | YES |
We will beat any advertised price on the same product. |
|
Dimensions
| Exterior Dimensions (H x W x D) |
31" x 26" x 25.25" |
|---|---|
| Overall Exterior Depth (with handle installed) |
28.5 |
| Interior Dimensions (H x W x D) |
25 x 20 x 16 |
| Clear Door | 25 x 20 |
| FOOTPRINT (W x D) |
26 x 25.25 |
| Exterior Cubic Feet (safe body only) |
11.8 |
| Interior Cubic Feet | 4.6 |
| Door Swing Projection at 90° | 49.125 |
| Door Swing Projection at 180° | 47.5 |
Fire Protection
| Fire Rating | 2 hrs. w/ Max Temp. of 1850° |
|---|---|
| Fire Temp | Temperatures Up To 1850° |
| Fire Insulation Type | Concrete exceeding 12,000 PSI |
| Door Seal | Heat-Activated, Expanding Palusol™ |
| Smoke Seal | YES |
Security
| Security Rating | U.L. Listed TL-30x6 |
|---|---|
| Door Bar / Bolt Sides | 3 sided coverage (2 active side)** |
| Bar / Bolt Count | 7 |
| Bar / Bolt Type | 1.25 Steel Round Bolt (Chrome) |
| Locking Mechanism Type | Direct Cam-Drive |
| Door Type | Propreitary, Not Disclosed |
| Door Thickness | 6" |
| Body Steel Thickness | Propreitary, Not Disclosed |
| Total Body Thickness | 3" Made of 5 different security barriers. |
| Main Lock | U.L. Listed S&G Dial or Titan Pivot E-Lock |
| Secondary Lock | S&G 6870 Auxiliary High Security Keylock |
| Relocker Type | Spring Loaded Relocker w/ optional glass |
| Hardplate Lock Protection | Tool Steel Hardplate w/ Active Roll Pins |
| Anchor Holes | Optional (1) 9/16" Floor |
Style
| Exterior Finish | Black Textured |
|---|---|
| Fabric Type | NONE, Color Match to Exterior |
| Upholstery | NONE, Color Match to Exterior |
| Handle Style | 3 Spoke Chrome |
| Interior Type | 1 Shelf (Tan) |
| Power Access Hole | YES |
| Interior Lighting | optional |
| Door Panel | NO |
